HIGHTOP MACHINERY
| Basic Feature | External dimensions (mm) | 5800 Length *2480 Width *2560 Height | |
| Internal Dimensions(mm) | 5640 Length *2320 Width *2400 Height | ||
| Folded state(mm) | 5800*2480*380 | ||
| Total mass (kg) | 1000 | ||
| Framework | top beam | Q235B Rectangular square tube 60×80×1.5mm | |
| Bottom girder | Q235B Rectangular square tube 80×140×1.5mm | ||
| Front and rear main beam | Q235B Rectangular square tube 60×80×1.5mm | ||
| side wall frame | Q235B Rectangular square tube 40×80×1.5mm | ||
| Bottom load | Q235B Rectangular square tube 40×40×1.5mm | ||
| Top load | Q235B Rectangular square tube 40×40×1.5mm | ||
| Hanging head | Q235B 125*200*（4mm) | ||
| Folding hinge | Galvanized hinge 13mm | ||
| Roof | Integral frame protective coating | Electrostatic spray / high gloss white | |
| External roof | Galvanized sheet 0.5mm | ||
| Interior ceiling | Color steel veneer V930*0.25mm | ||
| Wall panel | Insulation glass wool | Glass wool roll 50mm (density 16 kg) | |
| Side wall | 65mm composite board 0.23mm basalt wool (volume weight 50 kg) 0.23mm | ||
| Front and rear wall panels | 65mm composite board 0.23mm basalt wool (volume weight 50 kg) 0.23mm | ||
| Floor | Fireproof glass magnesium floor 15mm | ||
| Electrical System | Electrical wiring is installed in strict accordance with moisture-proof specifications, and all electrical products must comply with CE certification. Connect the circuit according to the circuit engineering specification, indoor: 4² national standard annealed copper wire, 1 20A circuit breaker, 2.5² socket inlet, 1 five-hole single-open socket, 1 air-conditioning socket, 1 lamp. | ||
| Ordinary security door | High-quality anti-theft door (warm white) size: 930mm*1970mm | ||
| Window | 930*930 plastic-steel anti-theft integrated window, glass thickness 4mm (warm white) | ||
| Quality assurance | The whole box meets the Class A fire protection standard. One year warranty (China) | ||
