HT2ton-2.5ton electric forklift

HT2-2.5 ton electric forklift

Model

HT20

HT25

Rated capacity

2000kg

2000kg

Load center

500mm

500mm

Lift height

3000mm

3000mm

Free lift height

30mm

130mm

Fork size(L*W*T)

1070*120*40mm

1070*120*40mm

Fork outside spread(Min./Max.)

300/1200mm

300/1200mm

Mast tilt range(F/R)

6/12deg

6/2deg

Front overhang

482mm

482mm

without of fork

2480mm

2630mm

with fork

3550mm

3700mm

wheel width

1150mm

1150mm

Mast lowered height

2090mm

2090mm

Mast extended height

4050mm

4050mm

Overhead guard height

2120mm

2120mm

Turning radius

2320mm

2380mm

Min. right angle aisle width

1910mm

2000mm

Travel speed (unload/full load)

18km/h

18km/h

Lift speed (unload/ full load)

300mm/s

300mm/s

Self weight

3600kg

3900kg

Max. gradeability

15°

15°
